Terminal Block, PCB, 5mm, 2 Way

SKU C3-CN15848
Original price £7.57
Original price £7.57 - Original price £7.57
Original price £7.57
Current price £6.31
£6.31 - £6.31
Current price £6.31
Save 17% Save 17% (£1.26)
Availability:
Only 5 left!
The 282836-2 is a 2-position 1 row 5mm PCB mount Terminal Block with vertical through hole orientation and side wire entry angle. It has tin-plated brass contacts, nickel-plated M3 brass screws in a polyamide 6.6 GF green housing and Interlocking system, screw wire connection method and accepts 30AWG to 16AWG wires.

End-to-end stackable with interlock and without loss of centreline spacing

Green colour

Polyamide 6.6 - GF material

Receptacle style 

Side wire entry angle

Without stacked levels 

Brass contact

Tin plating

-40 to +105°C Temperature range

M3 Screw size

UL94V-0 Flammability rating

Applications

Commercial, Industrial

Pitch Spacing: 5mm

No. of Positions: 2Ways

Wire Size AWG Min: 30AWG

Wire Size AWG Max: 16AWG

Conductor Area CSA: 1.4mm²

Wire Connection Method: Screw

Rated Current: 13.5A

Rated Voltage: 300V

Block Orientation: Through Hole Vertical

Product Range: Termi-Blok 5mm PCB Mount
