Socket Panel Rear Mount

SKU C3-CN13300
by BINDER
Original price £16.99
Original price £16.11 - Original price £17.03
Original price £16.99
Current price £12.78
£12.00 - £12.81
Current price £12.78
Save 25% Save 25% (£4.22)
Availability:
Out of stock
Availability:
in stock, ready to be shipped
Availability:
in stock, ready to be shipped
The 09 0112 00 04 is a 4-contact 250V/6A shielded straight subminiature female Circular Connector with gold-plated bronze contacts, PA (UL94V-0) contact body and nickel-plated zinc die-cast housing. The 723 series receptacle with M16 screw locking system, solder termination, front mounting. It accepts 20AWG (0.75mm²) wire. It provides excellent EMI shielding via a shielding ring or cable clamp and internal strain relief.

1500V Rated impulse voltage

<=3mR Volume resistivity

>500 mating cycles Mechanical operation

IP67 Protection rating

Applications

Industrial

Product Range: 723 Series

Circular Connector Shell Style: Panel Mount Receptacle

No. of Contacts: 4Contacts

Circular Contact Type: Solder Socket

Connector Body Material: Brass Body

Contact Material: Bronze

Contact Plating: Silver
